240V 3PH 13.5KW Fixed Overhead Radiant Heater by Chromalox - STAR-14A-23-F


240V 3PH 13.5KW Fixed Overhead Radiant Heater.

Usually ships in 20 DAYS

SKU: STAR-14A-23-F Categories: ,


240V 3PH 13.5KW Fixed Overhead Radiant Heater.


The Chromalox ChromaStar infra-red comfort heaters are designed to provide a rugged source of heat for use in areas where dependence on air movement is impractical. The heaters are versatile, designed to provide warmth directly where it is needed for primary or spot heating applications. Each unit is constructed for long life and requires minimal maintenance. There are no moving parts or motors to wear out, no air filters or lubrication required.

All Chromalox ChromaStar radiant heaters feature the exclusive "Arctic End Patent Pending heating element terminal construction. This feature lowers the terminal box temperatures resulting in extended element and wiring life.

Extruded aluminum housings are rigid to provide added protection to the heating elements located at the focal point of a built-in mirrored aluminum reflector(s).

The heater(s) consist of hairpin bent .430 diameter alloy sheath tubular element(s) constructed of high quality resistance wire embedded in carefully selected MgO refractory insulation. The element feature "Arctic end terminal construction for longer life and cooler terminal enclosure temperatures. The element(s) also feature terminal construction using a waged-in silicone bushings that produce unequaled resistance to moisture absorption. The heating element(s) connect to a gasketed, moisture resistance terminal enclosure with liquid-tight bulkhead threaded fittings. An extension reflector constructed of 0.050 mirrored aluminum extends over the assembly to provide a more uniform heating pattern.

Fixed Overhead

The Chromalox ChromaStar radiant heater is shipped fully assembled and can be hung from thee ceiling with 2 chains or rigid angle brackets attached to the heater brackets located on the back of the heater. Field wiring is accomplished through the liquid tight terminal enclosure. No secondary splice box required. Protective screens, disconnect switches and portable carts are available for these heaters as shown.


  • Localized heating in large plants
  • Loading Docks
  • Narrow warehouse aisle heating
  • Garages
  • Dry paint
  • Prevent freezing of pipes, valves
  • Heat hoppers

Click here for specification sheet.

Click here for installation sheet.

Additional information

Weight 800 oz
Dimensions 1 × 1 × 1 in
